Pilot Tecthrone Series Seat

Pilot Tecthrone Series Seats

The Pilot Tecthrone Series is a range of compact low-profile mechanical suspension seats suitable for forklift trucks, pavers, rollers, and other small construction and light plant machinery. They are available in a number of different sizes with different suspension strokes, to suit a wide range of small to medium-sized plant and construction machinery.

Specifications:

• Mechanical suspension
• Weight adjustment up to 150kg
• Suspension stroke:

  • 20/MN60 model (mini) - low-profile 60mm suspension stroke
  • 21/MN60 model (small) - low-profile 60mm suspension stroke
  • 22/MN60 model (medium) - low-profile 60mm suspension stroke
  • 23/MN80 model (large) - low-profile 80mm suspension stroke
• Slide rail adjustment - 210mm
• Backrest adjustment
• Black vinyl

Accessories:

• Armrests
• Hip guards
• Headrest / backrest extension
• Static or retractable lap belt
• Operator presence switch
• Seat heating
• Document box
• Turntable
